Wall Mounted Waterproof Digital Signage IP66 LCD 55"

Wall Mounted Waterproof Digital Signage IP66 LCD 55"

Product Details:

Place of Origin: China
Brand Name: Fengshi LCD
Certification: CE,EMC
Model Number: FSOD650-D20

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: USD1800/PC-USD1900/PC
Packaging Details: Each display are packed with EPE in strong carton box CTN size:1385 x 1000 x 240 mm weight:78kg
Delivery Time: 18-25 Working Days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500PCS/Month
Get Best Price Contact Now

Detail Information

Pixels:: 1920 * 1080 Product Name:: Full Outdoor LCD Display
Dimension (mm):: 1281.2 X 752.4 X 96.5 Operating Temperature:: -30℃~ 50℃
Bezel Width (mm):: 34.8 / 34.8 / 34.8 / 34.8 Mm Color Gamut:: 72%
Operating System:: Android 7.1 Weight (kg):: 46.0kg
High Light:

Wall Mounted Waterproof Digital Signage

,

Waterproof Digital Signage IP66

,

55 inch lcds

Product Description

IP66 Waterproof LCD 55" Outdoor LCD Digital Signage Wall Mounted




Description



1. High brightness 3000nits-5000nits



The OD series possess powerful brightness of 5000 nits, providing clear and vivid picture quality even

under direct sunlight.


2. Automatic dimming sensor



The brightness will be varied with the brightness of the environment.


3. Industrial grade 110℃ high Tni panel, wide viewing angle



IPS technology provides better control of the liquid crystals, which in turn allows the screen to be viewed at
virtually any angle.


4.Full optical bonding in front of the screen, IP56 protection level



Each OD Series display undergoes rigorous IP56 ingress defense testing to ensure resistance to dust, heat,
moisture and other environmental variables that can impede operations. This includes an integrated self
-cooling system that keeps the OD Series displays running in temperatures ranging from -30oC (-22oF) to
50oC(122oF). In turn, operators can feel confident in the displays’ ability to perform 24/7, and without requiring
expensive external cooling systems or security measures.


5. Intelligent temperature control, cooling fan system





Drawing

Wall Mounted Waterproof Digital Signage IP66 LCD 55" 0





Parameter

Diagonal Size 55
Size Mearsure 54.6" / 138.7cm
Resolution 1920x1080 (16:9)
Pixel Pitch(mm) 0.630 x 0.630
Active Display Area(mm) 1209.60(H) x 680.40(V)
Brightness(Typ.) 5,000 cd/m2
Contrast Ratio 1,000:1
Viewing Angle(H/V) 178/178
Display Colors 8 bit - 16.7M
Color Gamut 72%
Operation Hour 7*24
Haze 2%
Dynamic C/R 100,000:1
Speaker Type N/A
Power Supply AC 100 - 240 V~ (+/- 10 %),
50/60 Hz
Max[W/h] TBD
Dimension (mm) 1281.2 x 752.0 x 95.5 mm
1410 x 1000 x 260 mm
Weight (kg) 49.0kg
78.0kg
Mounting Hole 1170 x 560 (Basic)
1200 x 400 (VESA Bracket-et Option)
Protection Glass 5mm
Bezel Width (mm) Even 33.8 mm
Operating Temperature -30~ 50
Humidity 10~100% (Non-condensing)
IP Certificate IP56
Processor Coretex Rockchip RK3288 Coretex A17 1.8GHz
Memory Interface HYNIX DDR3 2GB
Storage 8GB
Operating System Android 7.1
Multimedia
Video Decoder
MPEG-1/2/4, H.264, WMV,WKV,TS,FLV
JPEG, PNG, BMP, PNG,GIF
MP3



Wall Mounted Waterproof Digital Signage IP66 LCD 55" 1



Wall Mounted Waterproof Digital Signage IP66 LCD 55" 2



Wall Mounted Waterproof Digital Signage IP66 LCD 55" 3



FAQ




1.Q: Are you a manufacturer or trading company?

A: We are a professional manufacturer specialized in LCD panel/LCM since 2016 located in Shenzhen.



2. Q: How long is the warranty?

A: Our officially promised warranty time is 1 year or 18months(Non-artificial damages) from the date of

delivery.



3. Q: Do you provide ODM/OEM or customized service?

A: We’re BOE High-bright LCD ODM factory, OEM/ODM are available based on your requirements.

In order to support different customers, we are able to supply:

(1) High Brightness LCD Panel: LCD panel+led driver board+auto dimming sensor

(2) Open Frame LCD Displays: LCD Panel+PSU+AD board(optional interface, eg: HDMI, VGA, DVI,

USB...)+Touch optional

(3) Window Facing Displays: LCD Panel+PSU+AD board (network board optional)+fan system+tem-

perature control board+housing

(4) Full Outdoor Displays: customized. eg: touch function, IP55/IP65 etc.



4. Q: What brand of OC do you use?

A: Original LG/SAMSUNG/AUO/BOE etc. A or A+ grade OC, we can guarantee each display will pass

through strict quality inspection.



5. Q:What certifications you have?

A:The CE-EMC Certificate of Conformity, ISO certification, FCC certification.



6.Q:What is the temperature when the screen surface goes black?

A: Normal grade goes black over 68℃;industrial grade goes black over 105 or 110℃.



7.Q: What is the MOQ?

A: Sample testing is acceptable, the price is negotiable for bulk order.



8.Q: When will you delivery?

A: High brightness LCD panel sample order shipped in 3days, bulk order shipped within 2 weeks.
